Features
  • Improved multifunction capability increases productivity
  • Larger capacity at 550 lb
  • More durability and serviceability thanks to the new DuraTough hood design
  • Auxiliary Power: 12 Volts DC
  • Axle Oscillation: 4 in. / 0.1 m
  • Capacity - Fuel Tank: 16 gal. / 60.57 L
  • Capacity - Hydraulic Reservoir: 36 gal. / 136.27 L
  • Drive Speed - 4WD: 4.50 mph / 7.24 km/h
  • Engine Type - Diesel: Deutz D2.9 L4 Tier 4 Final 49 hp
  • Engine Type - Dual Fuel: GM Vortec 3000 MPFI 82 hp
  • Gradeability - 4WD: 45 %
  • Ground Bearing Pressure: 48 psi / 3.36 Kg/cm2
  • Ground Clearance: 1 ft / 0.3 m
  • Horizontal Outreach: 25 ft / 7.62 m
  • Machine Height: 7 ft 5 in. / 2.27 m
  • Machine Length: 21 ft 7 in. / 6.58 m
  • Machine Length - Transport: 21 ft 7 in. / 6.58 m
  • Machine Weight: 12650 lb / 5737.94 kg
  • Machine Width: 7 ft 9 in. / 2.35 m
  • Platform Capacity - Unrestricted: 550 lb / 249.48 kg
  • Platform Dimension A: 2 ft 6 in. / 0.76 m
  • Platform Dimension B: 6 ft / 1.83 m
  • Platform Height: 45 ft / 13.72 m
  • Platform Height: 45 ft / 13.72 m
  • Swing: 355 Degrees
  • Swing Type: Non-Continuous
  • Tailswing: Zero
  • Tire Size: 33/1550 x 16.5 Superwide
  • Turning Radius - Outside: 15 ft 8 in. / 4.78 m
  • Up and Over Height: 24 ft / 7.32 m
  • Vertical Jib Rotation: 144 Degrees

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/articulating-booms/450AJ

450AJ-Articulating-Boom-Spec-Sheet
Engine Powered AWP Brochure
