Features
  • Best reach envelope in its class
  • Optional articulating jib gets you into hard-to-reach places
  • Narrow chassis for confined work areas
  • Equipped with a fuel-efficient Tier 4 engine
  • Auxiliary Power: 12 Volts DC
  • Axle Oscillation: 8 in. / 0.2 m
  • Capacity - Fuel Tank: 30 gal. / 113.56 L
  • Capacity - Hydraulic Reservoir: 31 gal. / 115.83 L
  • Drive Speed - 2WD: 4.25 mph / 6.84 km/h
  • Engine Type - Diesel: DEUTZ TD 2.9L Tier 4 Final 67 hp
  • Engine Type - Dual Fuel: GM Vortec 3000 MPR, 82 hp
  • Gradeability - 2WD: 30 %
  • Ground Bearing Pressure: 94 psi / 6.58 Kg/cm2
  • Ground Clearance: 1 ft / 0.3 m
  • Horizontal Jib Rotation: 0 Degrees
  • Horizontal Outreach: 39 ft 9 in. / 12.12 m
  • Machine Height: 8 ft 4 in. / 2.54 m
  • Machine Length: 29 ft / 8.83 m
  • Machine Weight: 24200 lb / 10976.94 kg
  • Machine Width: 7 ft / 2.13 m
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Platform Dimension A: 3 ft / 0.91 m
  • Platform Dimension B: 8 ft / 2.44 m
  • Platform Height: 60 ft 7 in. / 18.47 m
  • Platform Height: 60 ft 7 in. / 18.47 m
  • Swing: 360 Degrees
  • Swing Type: Continuous
  • Tailswing: 5 in. / 0.13 m
  • Tire Size: 14 x 17.5 Air Boss
  • Turning Radius - Outside (4WS): 11 ft 2 in. / 3.4 m
  • Up and Over Height: 26 ft 7 in. / 8.1 m
  • Vertical Jib Rotation: 130 Degrees

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/articulating-booms/600AJN Narrow

Engine Powered AWP Brochure
600 Series Articulating Boom Lift Spec Sheet
