Features
  • Accessibility up and over access, optional jib
  • Productivity work longer with longer duty cycles
  • Maneuverability move over uneven surfaces with the Automatic Traction Control option
  • Environmentally friendly zero emissions
  • Versatility Three platform heights and jib and non-jib options; three chassis widths to fit any workspace; electric or multi-fuel
  • Batteries: 8 x 6V, 370 amp-hr
  • Capacity - Hydraulic Reservoir: 4 gal. / 15.14 L
  • Drive Speed - Platform Lowered: 3.20 mph / 5.15 km/h
  • Electrical System: 48 Volts DC
  • Gradeability - 2WD: 30 %
  • Ground Clearance: 9 in. / 0.22 m
  • Horizontal Jib Rotation: 0 Degrees
  • Horizontal Outreach: 23 ft 9 in. / 7.24 m
  • Machine Height: 6 ft 7 in. / 2.01 m
  • Machine Length: 21 ft 2 in. / 6.45 m
  • Machine Weight: 14400 lb / 6531.73 kg
  • Machine Width: 5 ft 9 in. / 1.75 m
  • Platform Capacity: 500 lb / 226.80 kg
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Platform Dimension A: 2 ft 6 in. / 0.76 m
  • Platform Dimension B: 5 ft / 1.52 m
  • Platform Height: 45 ft / 13.72 m
  • Platform Height: 45 ft / 13.72 m
  • Swing: 360 Degrees
  • Swing Type: Non-Continuous
  • Tailswing: Zero
  • Tire Size: 240/55-17.5 Pnuematic
  • Turning Radius - Outside: 10 ft 4 in. / 3.15 m
  • Up and Over Height: 25 ft 3 in. / 7.7 m
  • Vertical Jib Rotation: 141 Degrees
  • Wheelbase: 6 ft 7 in. / 2.01 m

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/articulating-booms/E450AJ

Electric Powered AWP Family Brochure
