• Max Horizontal Reach: 22 ft 3 in | 6.78 m
  • Max Up and Over Clearance (riser extended): Z-34/22 IC 2WD: 15 ft | Z-34/22 IC 4WD: 15 ft 1 in | Z-34/22 IC 2WD: 4.57 m | Z-34/22 IC 4WD: 4.6 m
  • Max Working Height: Z-34/22 IC 2WD: 40 ft 6 in | Z-34/22 IC 4WD: 40 ft 10 in | Z-34/22 IC 2WD: 12.52 m | Z-34/22 IC 4WD: 12.62 m
  • Platform Capacity: 500 lb | 227 kg

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/articulating-booms/Z-34/22 IC

Booms Family Brochure 2019
Boom Options Brochure 2019
Z-34/22 Product Specifications 2019
