Features
  • Quieter, cleaner operation for a variety of environments
  • Delivers 200% more battery life
  • Narrow width fits through most standard doorways and tight aisles
  • Electric drive and integrated components with only two hydraulic hoses and four hydraulic fittings on the entire machine will keep you on the job longer and reduce your operating costs by reducing chances for leaks and service calls
  • Batteries: 4 x 6V, 220 amp-hour
  • Brakes: Electric, Friction
  • Capacity - Hydraulic Reservoir: 1 gal. / 4.73 L
  • Charger: 20 amp automatic (120V/240V 50/60Hz)
  • Drive Speed - Platform Elevated: 0.50 mph / 0.80 km/h
  • Drive Speed - Platform Lowered: 3 mph / 4.83 km/h
  • Drive System: 24V Electric
  • Gradeability: 25 %
  • Ground Bearing Pressure: 109 psi / 7.63 Kg/cm2
  • Ground Clearance: 4 in. / 0.09 m
  • Hydraulic Pump: Fixed Displacement Gear
  • Lift Time: 26 sec.
  • Lower Time: 30 sec.
  • Machine Height: 6 ft 6 in. / 1.98 m
  • Machine Length: 6 ft 2 in. / 1.87 m
  • Machine Weight: 2710 lb / 1229.24 kg
  • Machine Width: 2 ft 6 in. / 0.76 m
  • Maximum Drive Height: 18 ft 9 in. / 5.72 m
  • Maximum Lift Height: 19 ft / 5.72 m
  • Platform Capacity - Extension: 250 lb / 113.40 kg
  • Platform Capacity - Unrestricted: 500 lb / 226.80 kg
  • Platform Dimension A: 2 ft 6 in. / 0.76 m
  • Platform Dimension B: 6 ft 2 in. / 1.87 m
  • Platform Extension Length: 3 ft / 0.9 m
  • Platform Height: 18 ft 9 in. / 5.72 m
  • Platform Height: 18 ft 9 in. / 5.72 m
  • Platform Height - Lowered: 2 ft 10 in. / 0.86 m
  • Platform Railing Height: 3 ft 7 in. / 1.1 m
  • Tire Size: 12.5 x 4 in
  • Turning Radius - Outside: 5 ft 9 in. / 1.75 m
  • Wheelbase: 5 ft 3 in. / 1.6 m
  • Working Height: 24 ft 9 in. / 7.54 m

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/scissor-lifts/1930ES

Electric Powered AWP Family Brochure
ES Series Spec Sheet
