1055

Key Specs

  • Maximum Lift Capacity: 10000 lb / 4535.92 kg
  • Outriggers Up Max Lift Height: 55 ft / 16.76 m
  • Maximum Lift Height: 55 ft / 16.76 m
  • Maximum Reach: 42 ft / 12.8 m

Key Features

  • Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
  • Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance
  • Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera
  • Increased versatility—wide range of attachment options

Features

  • Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
  • Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera
  • Increased versatility—wide range of attachment options
  • Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance
Specifications

  • Outriggers or Stabilizers: Yes
  • Machine Height: 8 ft 4 in. / 2.54 m
  • Frame Leveling: 10 Degrees
  • Speed - Maximum Lower: 11 sec.
  • Outriggers Up Max Forward Reach: 42 ft / 12.8 m
  • Axle-Rear: Planetary
  • Maximum Engine RPM: 1500 rpm
  • Speed - Maximum Lift: 14 sec.
  • Lift Capacity at Full Height: 5000 lb / 2267.96 kg
  • Ground Clearance: 1 ft 6 in. / 0.46 m
  • Lift Capacity at Max Reach: 3000 lb / 1360.78 kg
  • Speed - Maximum Telescope In: 15 sec.
  • Operating Vehicle Weight: 31559 lb / 14314.92 kg
  • Service Brake Type: Wet Multi-Disc
  • Function Pump Type: Load Sensing Piston
  • Machine Width: 8 ft 5 in. / 2.56 m
  • Load Center: 2 ft / 0.61 m
  • Speed - Maximum Travel: 20 mph / 32.19 km/h
  • Capacity - Fuel Tank: 38.3 gal. / 144.98 L
  • Machine Length: 20 ft 1 in. / 6.12 m
  • Speed - Maximum Telescope Out: 16 sec.
  • Transmission - Nr Forward Gears Standard: 4
  • Outriggers Up Max Lift Height: 55 ft / 16.76 m
  • Tire Size: 400/75-28
  • Maximum Lift Capacity: 10000 lb / 4535.92 kg
  • Wheelbase: 11 ft 6 in. / 3.49 m
  • Axle-Front: High Bias, Limited Slip
  • Transmission Type: Powershift
  • Engine Manufacturer: Cummins
  • Engine Horsepower: 130 hp / 96.98 kW
  • Engine Model: QSF3.8L Tier 4 F
  • Outside Turning Radius: 14 ft / 4.27 m
  • Transmission - Nr Reverse Gears: 3
  • Drawbar Pull: 25400 lb / 11521.25 kg
