Features
  • ROPS/FOPS canopy (ISO compliant), retractable seat belt and illuminated gauge and switch panels
  • Proportional, reversible, continuous auxiliary hydraulic flow
  • Power-assisted steering
  • Easy-to-use, multifunction joystick control for precise positioning
  • Variable-speed hydrostatic drive
  • Manual Genie Quick-Attach™ system for attachments
  • Two diesel engine options available
  • Full-time planetary four-wheel drive and four-wheel steer
  • Comfortable, spacious cab with tilt steering and ergonomic controls
  • Forward Reach: 11 ft (3.35 m)
  • Lift Capacity: 5,500 lbs (2,500 kg)
  • Lifting Height: 19 ft (5.79 m)
  • Maximum Forward Reach: 11 ft (3.35 m)
  • Maximum Lift Capacity: 5,500 lbs (2,500 kg)
  • Maximum Lift Height: 19 ft (5.79 m)
  • Power Source: Perkins 804D-33 4 cylinder diesel 63 hp (47.0 kW) Deutz D 2011 4 cylinder diesel 68 hp (50.0 kW)
  • Travel Speed: 15 mph (24.1 km/h)
  • Weight*: 9,800 lbs (4,450 kg)

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/telehandlers/GTH™-5519

GTH-5519 Product Specifications
Telehandler Family Brochure 2015

Other Telehandlers Models
