S-40 XC and S-45 XC

Telescopic Booms

The Genie® S-40 XC™ and S-45 XC™ telescopic booms are engineered to work in more applications that require higher capacities. With industry-leading dual lift capacity — 660-lb (300 kg)/1,000-lb (454 kg) — a smooth operating envelope, this new XC boom lift is a perfect fit for your customers’ heavy lifting in construction, bridge inspections and maintenance, stadium and sports arena, gas and oil refineries, industrial, telecommunications and utility applications.

Overview

  • 660-lb (300 kg)/1,000-lb (454 kg) dual platform capacity
  • Load sense technology for accurate load weighing and zero-load field calibration
  • Automatic envelope control enables boom to retract when it reaches its operating envelope
  • Chassis tilt sensor technology maximizes operators’ ability to access hard-to-reach work areas
  • Robust jib is capable of easily handling increased maximum capacity
  • CAN-bus control system with onboard diagnostics maximizes serviceability
  • Design focus on user interface and simplicity makes this machine easy-to-use
  • Can be equipped with the new Genie Lift Powerâ„¢ generator system
  • Commonality in design and parts with other Genie booms

Specifications

  • Max Horizontal Reach: S-40 XC: 31 ft 8 in / S-45 XC: 36 ft 2 in | S-40 XC: 9.67 m / S-45 XC: 11.02 m

  • Platform Capacity: 660 lb Unrestricted, 1,000 lb Restricted | 300 kg Unrestricted, 454 kg Restricted

  • Below Ground Reach: S-40 XC: 1 ft / S-45 XC: 4 ft 2 in | S-40 XC: 0.30 m / S-45 XC: 1.27 m

  • Max Working Height: S-40 XC: 46 ft / S-45 XC: 51 ft | S-40 XC: 14.19 m / S-45 XC: 15.72 m

  • Machine Width and Length: 8 ft 2 in, 31 ft 1 in | 2.49 m, 9.47 m


Chassis Options

  • Tow package

Tire Options

  • Rough terrain foam-filled (standard)
  • Rough terrain non-marking (air or foam-filled)
  • Trax (track system)

Engine Options

  • 49 hp (36.54 kW) Deutz diesel T4f (standard)
  • 48 hp (35.79 kW) Perkins turbo diesel T4f 404F-E22T
  • 60hp (44.74kW) Ford Gas/LPG

Lift/Turntable Options

  • Specialty hydraulic oil (60 gal – cold weather, fire resistant, or biodegradable)
  • LPG tank, 33.5 lb. capacity: Ford engine only
  • Second battery
  • Hostile environment kit: cylinder bellows, boom wiper seals, platform and ground control box covers
  • Deluxe hostile environment kit: hostile environment kit, ring gear guard, cable track hose cover, air pre-cleaner

Platforms

  • Steel 8 ft (2.44 m) tri entry with side swing gate (standard)
  • Steel 6 ft (1.83 m) dual entry with side swing gate

Platform Options

  • Lift Powerâ„¢ 3kW AC generator, 110V/60Hz or 220V/50Hz
  • Air line to platform: ½ in. inner diameter
  • Aircraft protection kit:  platform foam padding and padded disable system
  • Aircraft protection kit: with swing gate
  • Light package: 2 chassis mounted drive lights and 2 platform mounted work lights
  • Lockable platform and ground control box covers
  • Panel cradle package
  • Platform auxiliary top rail
  • Thumb rocker steering
  • Lift Powerâ„¢ 12kW Welder – Select Lincoln or Miller
  • Lift Powerâ„¢ 12kW Welder Ready package
  • Traveling fall arrest anchor system: requires 6ft platform
  • Traveling fall arrest anchor system: requires 8ft platform
