Features
  • Gasoline engine or 24V DC electric power
  • Accessory Mounting Tray accommodates your generator, air compressor or pressure washer
  • Standard air and water lines to platform
  • Batteries: 4 x 6V 220 amp-hr
  • Capacity - Hydraulic Reservoir: 4 gal. / 15.14 L
  • Frame Leveling: 11 Degrees
  • Ground Bearing Pressure: 23 psi / 1.61 Kg/cm2
  • Ground Clearance: 1 ft 2 in. / 0.36 m
  • Ground Entry Height: 10 in. / 0.25 m
  • Horizontal Outreach: 18 ft 8 in. / 5.69 m
  • Leveling Capability: 11 Degrees
  • Machine Height: 6 ft 6 in. / 1.98 m
  • Machine Length: 21 ft 9 in. / 6.63 m
  • Machine Weight: 3400 lb / 1542.21 kg
  • Machine Width: 4 ft 9 in. / 1.45 m
  • Outrigger Footprint Length: 11 ft 7 in. / 3.53 m
  • Outrigger Footprint Width: 10 ft 5 in. / 3.18 m
  • Outriggers or Stabilizers: Yes
  • Platform Capacity: 500 lb / 226.80 kg
  • Platform Dimension A: 2 ft 6 in. / 0.76 m
  • Platform Dimension B: 4 ft / 1.22 m
  • Platform Height: 35 ft / 10.67 m
  • Platform Height: 35 ft / 10.67 m
  • Swing: 410 Degrees
  • Swing Type: Non-Continuous
  • Tire Size: 205/75 R14 Pnuematic
  • Towing Speed Rating: 65 mph / 104.61 km/h
  • Up and Over Height: 15 ft / 4.57 m
  • Vertical Jib Rotation: 0 Degrees

Documentation

Download at http://www.riekesequipment.com/new-equipment/aerial-lifts/telescopic-booms/T350

Tow-Pro Series spec sheet
Electric Powered AWP Family Brochure
