• The standard extended shift feature provides an excellent balance between battery runtime and truck productivity, and operator selectable performance modes further increase efficiency in multi-task operations.
  • The new platform utilizes AC motors and transistor controller technology for both the traction and hydraulic systems, reducing the frequency and cost of maintenance.
  • The "zero Turn" radius steer axle and Dual AC Drive motors combine to provide extraordinary maneuverability Yale designed thermal management system maximizes performance during continuous operation, while preventing damage to components due to heat
  • Wet disc brakes are employed in conjunction with the power assist braking system to reduce brake effort, extend brake life, provide increased stopping power and eliminate brake squeal sometimes associated with drum brakes.

  • Model Load Capacity (lbs.) Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
    ERP080VM 8000 13 118
    ERP090VM 9000 13 93
    ERP100VM 10000 13 93
    ERP110VM 11000 13 91
    ERP120VM 12000 13 91
  • Capacity: 8,000-12,000 lbs
  • Max Height: 236
  • Max Weight: 12,000 lbs
  • Series Title: ERP080-120VM
  • Type: Electric Four-Wheel Pneumatic Tire Truck
  • Weight: lbs


Download at http://www.riekesequipment.com/new-equipment/forklifts/4-wheel-electric/ERP080-120VM

ERP080-120VM Product Brochure
ERP080-120VM Spec Sheet
