B40i5

Bendi Rear Wheel Drive Narrow Aisle Multipurpose LP Gas Forklift

The Bendi model B40i5 works in aisles as narrow as *78″ (1.98M), has a basic capacity of 4,000 lbs. (1814kg) at 24″ (600mm) load center and has lift heights available to 30′ (9.14M). The LP Gas engine provides the ability to run 24/7 without battery changing or charging.

The B40i5 is a 4-wheel articulating forklift with dual rear-drive tires and soft-poly front load tires. The hydrostatic drive provides excellent traction and braking, high speed capability and power to enable climbing steep ramps with loads. Three or four stage masts are available making this unit excellent for loading/unloading trailers, containers and highway trailers. The B40i5 can work inside and outside on paved surfaces and has a floating front axle allowing the truck to ride smoothly over uneven floors. The Bendi B40i5 does all of the jobs of reach and counterbalanced trucks but in much narrower aisles.

Exceptional Performance and Maneuverability

Equipped with the Landoll DuraSteerTM front wheel hydraulic steering, the B40i5 provides exceptional control and makes load placement and retrieval superior to the competition.

Maximizes Material Handling Productivity

The versatile Bendi B40i5 forklift replaces conventional reach and counterbalanced fork trucks in standard warehouse operations. The unique design allows operators to use it as a counterbalance truck indoors or out, yet operates in narrow aisles in your warehouse, replacing reach trucks that require much wider aisles. The Bendi B40i5 has large diameter tires and the truck has great underclearance for avoiding floor obstructions. One forklift can go from inside the truck to the rack eliminating staging and additional operators and support forklifts.

*Based on 48” (1200mm) long x 40” (1000mm) wide load.

Features

  • DuraSteerTM Front Wheel Hydraulic Steering Provides Smooth, Reliable, Long-Lasting Steering Control
  • Engine RPM is Controlled Automatically for all Hydraulic Functions without the Need for an Inching Pedal
  • Integral Wide Stroke Sideshifter Makes Placing and Picking Loads Effortless
  • High Visibility Mast Allows Optimum Safety and Control
  • Hydrostatic Braking Assures Automatic Smooth and Safe Braking when the Operator Removes Foot from the Accelerator Pedal
  • Four-Wheel Design, Dual Rear Wheel Drive Provides Excellent Power, Braking and Traction with Fast Travel Speeds
  • Ergonomic Design for Exceptional Operator Comfort and Safety
Specifications

  • Capacity: 4000 lbs / 1814 kg
  • Fork Carriage Width: 41 in / 104 cm
  • Fork Length: 40 in / 101.5 cm
  • Fork Spread: 9.4 in max - 39.5 in min / 24 in max - 100 in min /
  • Gradeability (loaded): 15%
  • Gradeability (unloaded): 15%
  • HP Rating (LP Gas Engine @ 2600 RPM): 61.7 HP
  • Intersecting Aisle: 114 in / 289 cm
  • Lift Speed (loaded): 90 fpm / 27.4 mpm
  • Lift Speed (unloaded): 100 fpm / 30.5 mpm
  • Lost Load Center: 12 in / 30.5 cm
  • Lowering Speed (loaded): 100 fpm / 30.5 mpm
  • Lowering Speed (unloaded): 90 fpm / 27.4 mpm
  • Mast Tilt (Up to 293 inches): 3 deg fwd / 3 deg back
  • Mast Tilt (Up to 294 inches and higher): 1 deg fwd / 2 deg back
  • Operator Floor Height: 31 in / 79 cm
  • Overall Length to Face of Forks: 109 in / 277 cm
  • Overhead Guard Height: 87 in / 221 cm
  • Overhead Guard Width: 40 in / 101.5 cm
  • Rear Overhang: 28 in / 71 cm
  • Right Angle Stacking Aisle: 78 in / 198 cm
  • Travel Speed (loaded): 8 mph / 13 kph
  • Travel Speed (unloaded): 8 mph / 13 kph
  • Underclearance: 10 in / 25 cm
  • Weight with Battery: 13700 lbs / 6214 kg
  • Wheel Size (front): 14x5 in / 36x13 cm
  • Wheel Size (rear): 18x7x12 in / 46x18x30 cm
  • Wheelbase: 69 in / 175.25 cm
  • Overall Width: 49 in / 124.5 cm
  • Intermediate Step Height: 19 in / 48 cm
