Features
  • Ergonomically advanced interior - the cab is designed around the operator for great visibility and maximum operator comfort.
  • Robust mast and front end design for a variety of applications in lumber, steel, concrete and general cargo applications. Designed for versatility with various front end attachments providing solutions in various industry segments.
  • On-demand cooling featuring a quad-cooler with four separate cooling cores (engine, transmission, charge air cooler and hydraulic system). The cores are horizontally stacked and are individually replaceable. The integrated hydraulic cooler maintains normal system operating temperatures at high ambient temperatures.
  • Right-sized powertrain displaces less fuel and delivers superior fuel consumption and a Lower Total Cost of Ownership (TCO).
  • The H190-280XD features a Cummins QSB 4.5L diesel Tier 4 Final diesel engine with a turbocharger and intercooler mated to a powerful 3 – speed ZF WG 161 powershift transmission. EPA Tier 4 Final compliant with a Selective Catalytic Reduction (SCR) system using Urea (Diesel Exhaust Fluid), a Diesel Oxidation Catalyst (DOC), and a dosing module for urea injection.
  • Ease of serviceability for daily checks and routine maintenance with powered cab tilt and dual gull wing profile – Access key components in seconds.

Models
  • Model Load Capacity (lbs) Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
    H190XD 19000 19.4 136
    H210XD 21000 19.4 136
    H230XD 23000 19.9 102
    H230XDS 23000 19.9 102
    H250XD 25000 19.9 102
    H280XD 28000 19.9 102
  • Capacity: 19,000-28,000 lbs
  • Max Height: 275
  • Max Weight: 28000 lbs
  • Series Title: H190-280XD
  • Type: BIG TRUCK
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/high-capacity/H190-280XD

Hyster XD Series Cab Brochure
H190-360XD Brochure
H190-280XD Technical Guide
