Features
  • Operator compartment is designed for superb ergonomics and outstanding forward and rearward visibility. 3-way adjustable seat, 6-way adjustable arm rest control module “Soft touch” mini levers offer a more ergonomic design Includes multifunction display panel located to the right of operator  Lever controls or optional joystick provide optimum hydraulic control
  • Oil immersed wet disc brakes are incorporated in the drive axle to provide excellent control and longer life.
  • “Soft touch” mini levers offer a more ergonomic design
  • Automatic throttle-up provides automatic response to lift inputs from the operator when the lift lever is activated. Controlled rev-up keeps the engine in the most efficient band to deliver good fuel economy.
  • The electrical system utilizes sealed deutsch automotive quality connectors throughout. The wires are single colored and numbered for ease of tracing.
  • On demand cooling features hydraulically driven cooling fan that draws power only when cooling is required.
  • 3-way adjustable seat, 6-way adjustable arm rest control module
  • Cummins engine and SOH TE-32 transmission have shutdown systems monitoring low oil/high temperatures. The powertrain derate system helps prevent damage to the drivetrain and components by extending the life of engine oil, transmission and coolant fluids.
  • Includes robust and proven Dana Spicer Off-Highway (SOH) TE-32 powershift transmission.
  • Includes multifunction display panel located to the right of operator
  • Powered by a strong and reliable EPA Tier 4 Final compliant Cummins® QSL 9L diesel engine with 350 HP. Is equipped with an after treatment package featuring selective catalytic reduction (SCR), and diesel oxidation catalyst (DOC).e right of operator
  • Hibernate idle feature reduces engine idle speed to further conserve fuel.
  • Lever controls or optional joystick provide optimum hydraulic control
  • Features durable Kessler D102 drive axle.

Models
  • Model Load Capacity (lbs) Load Centre Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
    H800HD 80000 48 12.4 59
    H900HD 90000 48 12.4 59
    H970HD 97002 48 12.4 59
    H1050HDS 105821 48 12.4 59
    H1050HD 105821 48 12.4 59
  • Capacity: 80,000 - 105,000 lbs
  • Max Height: 275
  • Max Weight: 105000 lbs
  • Series Title: H800-1050HD/S
  • Type: BIG TRUCK
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/high-capacity/H800-1050HD/S

H800-1050HDS Brochure
H800-1050HD\S Technical Guide
