GC040-070VX

Rugged and Versatile with Customizable Options for Any Application

The GC040-070VX Veracitor® series offers a reliable and comprehensive parts program. Not only is the truck designed to require less maintenance, the Yale® dealer program provides off-the-shelf availability of maintenance and repair parts routinely serviced in the first two years of truck operation.

The GC040-070VX Veracitor® boasts innovative features and industry-leading power, while delivering maximum performance for medium to heavy duty applications. Two engine selections consisting of the Kubota 2.5L and PSI 2.4L engines offer multiple performance levels with low operating costs.

Features

  • The Yale® Veracitor® VX truck delivers maximum performance for medium to heavy duty applications with state-of-the art features and industry leading power.
  • For applications requiring the use of attachments; Yale® attachment ready models are available with a factory modified front end, which allow for seamless truck and Bolzoni Auramo attachment interface.
  • From the rear-opening, one-piece hood and on board diagnostics, to the reliable, most comprehensive parts availability in the industry, this truck was designed with service details in mind.
  • The Continuous Stability System (CSS™) enhances the truck's lateral stability with a simple, maintenance-free design that does not compromise uneven surface travel.
  • Operator comfort is enhanced by the increased foot space in the well designed operator's compartment. The isolated powertrain reduces noise and vibration, minimizing operator fatigue and increasing operator productivity throughout a shift.
  • Excellent operator visibility is afforded through the Yale® Global Hi-Vis™ mast.
Specifications

  • Max Height: 217
  • Type: Internal Combustion Cushion Tire Lift Truck
  • Capacity: 4,000 – 7,000 lbs
  • Max Weight: 7000 lbs
  • Series Title: GC040-070VX


Model Model Designation Load Capacity (lbs.) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
GC040VX Internal Combustion Trucks 4000 PSI 2.4L, Kubota 2.5L Electronic Powershift 1 Speed, Techtronix 100 Electronic 1 Speed 11.3 126
GC050VX Internal Combustion Trucks 5000 PSI 2.4L, Kubota 2.5L Electronic Powershift 1 Speed, Techtronix 100 Electronic 1 Speed 11.3 126
GC055SVX Internal Combustion Trucks 5500 PSI 2.4L, Kubota 2.5L Electronic Powershift 1 Speed, Techtronix 100 Electronic 1 Speed 11.3 126
GC060VX Internal Combustion Trucks 6000 PSI 2.4L, Kubota 2.5L Electronic Powershift 1 Speed, Techtronix 100 Electronic 1 Speed 11.2 110
GC070VX Internal Combustion Trucks 7000 PSI 2.4L, Kubota 2.5L Electronic Powershift 1 Speed, Techtronix 100 Electronic 1 Speed 11.2 110
