Features
  • Engine features Yale® Flex Performance Technology™, selectable performance modes that provide the flexibility to maximize fuel economy or productivity to match application requirements
  • On-demand hydraulic system featuring Accutouch mini-lever controls pumps oil only when required, reducing fuel consumption
  • Powertrain combinations include Kubota 3.8L spark-ignited LPG engine
  • Fully sealed wet disc brakes virtually eliminate brake maintenance and often last the life of the truck
  • Advanced transmissions are built for durability and patented controllability, while extending tire and brake life up to 50%
  • Ergonomic operator compartment includes optimized step height with non-slip tread, soft touch contoured hand grip and infinitely adjustable steer column
  • Combi-cooler contains an individual transmission oil cooler to maximize heat dissipation
  • Full venting package draws air into the engine compartment from higher on the truck to enhance airflow and avoid radiator clogging

Models
Model Model Designation Load Capacity (lbs.) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
GC080VX Internal Combustion Trucks 8000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 14 122
GC080VXBCS Internal Combustion Trucks 8000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.9 122
GC100VX Internal Combustion Trucks 10000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.8 112
GC100VXBCS Internal Combustion Trucks 10000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
GC120VX Internal Combustion Trucks 12000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
GC120VXPRS Internal Combustion Trucks 12000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
  • Capacity: 8,000 - 12,000 lbs
  • Max Height: 310
  • Max Weight: 12000 lbs
  • Series Title: GC080-120VX
  • Type: Internal Combustion Cushion Tire Lift Truck
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/internal-combustion/GC080-120VX

GC080VX Spec Sheet
GC080-120VX Brochure
GC100-120VX Spec Sheet
