Features
  • Combi-cooler contains an individual transmission oil cooler to maximize heat dissipation
  • On-demand hydraulic system featuring Accutouch mini-lever controls pumps oil only when required, reducing fuel consumption
  • Fully sealed wet disc brakes virtually eliminate brake maintenance and often last the life of the truck
  • Advanced transmissions are built for durability and patented controllability, while extending tire and brake life up to 50%
  • Engine features Yale® Flex Performance Technology™, selectable performance modes that provide the flexibility to maximize fuel economy or productivity to match application requirements
  • Full venting package draws air into the engine compartment from higher on the truck to enhance airflow and avoid radiator clogging
  • Ergonomic operator compartment includes optimized step height with non-slip tread, soft touch contoured hand grip and infinitely adjustable steer column
  • Powertrain combinations include Kubota 3.8L spark-ignited LPG engine

Models
Model Model Designation Load Capacity (lbs.) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
GC080VX Internal Combustion Trucks 8000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 14 122
GC080VXBCS Internal Combustion Trucks 8000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.9 122
GC100VX Internal Combustion Trucks 10000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.8 112
GC100VXBCS Internal Combustion Trucks 10000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
GC120VX Internal Combustion Trucks 12000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
GC120VXPRS Internal Combustion Trucks 12000 Kubota 3.8L LPG Electronically Controlled Powershift 1 & 2 Speeds, Techtronix100 Electronic 1 Speed, Techtronix100X Electronic 2 Speed 13.7 112
  • Capacity: 8,000 - 12,000 lbs
  • Max Height: 310
  • Max Weight: 12000 lbs
  • Series Title: GC080-120VX
  • Type: Internal Combustion Cushion Tire Lift Truck
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/internal-combustion/GC080-120VX

GC080-120VX Brochure
GC080VX Spec Sheet
GC100-120VX Spec Sheet
