Features
  • Oil cooled wet disc brakes provide excellent stopping power and extremely long service life. And they are completely sealed from water and dirt making them ready for your harshest environments.
  • Our ergonomically designed operator compartment includes an optimized step height with non-slip tread, soft touch contoured hand grip, and an infinitely adjustable steer column all designed to enhance productivity
  • Superior ergonomic design allows for easy driver access, excellent visibility and a choice of two choices of hydraulic controls enable your operator to maximize productivity.
  • The new modulated braking system utilizes hydraulic oil pressure to actuate the brakes. This enhanced design ensures full braking power while minimizing braking effort from the operator.
  • Patented DuraMatch™ transmission provides industry leading features that include the Auto Deceleration System, controlled rollback on ramps, controlled power reversals to move loads more efficiently with less operator fatigue and product damage.

Models
  • Model Load Capacity (lbs) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
    H170FT 17000 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L Tier 4i Turbo Diesel Standard: Techtronix 332 - 3 Speed 13.4 88
    H170FTS 17000 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L Tier 4i Turbo Diesel Standard: 2-Speed Powershift Optional: 3-Speed Techtronix 332 15 84
    H175FT 17500 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L Tier 4i Turbo Diesel Standard: Techtronix 332 - 3 Speed 13.3 86
    H190FT 19000 Standard: Kubota 3.8L DOC Tier 4 Final Turbodiesel Optional: Kubota 3.8L Tier 4i Turbo Diesel Standard: Techtronix 332 - 3 Speed 13.3 78
  • Capacity: 17,000 - 19,000 lbs
  • Max Height: 234
  • Max Weight: 19000 lbs
  • Series Title: H170-190FT, H170FTS
  • Type: 4 Wheel Pneumatic Tire
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/internal-combustion/H170-190FT, H170FTS

H170-190FT Brochure
H155-170FTS-Brochure
H170-190FT Technical Guide
