S30-35FT, S40FTS

Operator Preferred Ergonomics and Unmatched Performance



A versatile lift truck designed for indoor use, this truck series is ideally suited for a wide variety of applications such as warehousing, food and kindred products, and electronic and electrical equipment.

The S30-40FTS series trucks boast one of the lowest cost of operations, maximum uptime, operator preferred ergonomics and unmatched performance. The Fortis® line offers you powertrain choices designed to fit your application.

Features

  • Pacesetter VSMâ„¢ continuously monitors fluid levels and powertrain, reducing daily service checks and preventing major repairs.
  • Our one-piece steel floor plate is easily removed to provide quick service access and a molded rubber mat seals the floor area to reduce noise and vibration for a quieter, smoother ride.
  • The innovative DuraMatch transmission provides electronic inching and shift control with controlled power reversals and controlled roll back on ramps providing exceptional handling and maneuverability.
  • Our exclusive VISTAâ„¢ Mast offers high strength hot-rolled steel mast channels and flush-faced design which improves capacity retention at high lifts while compact cast steel cross members optimize visibility and rigidity.
  • Leak-free O-ring face seals help maximize uptime and an in-tank filter increases hydraulic fluid filtration by 60% for particles down to 10 microns significantly extending component life and creating a cleaner overall operation.
Specifications

  • Series Title: S30-35FT, S40FTS
  • Capacity: 3,000 - 4,000 lbs
  • Max Height: 228
  • Max Weight: 4000 lbs
  • Type: CUSHION TIRE FORKLIFT


Model Load Capacity (lbs) Engine Transmission Maximum Travel Speed (mph) Maximum Lift Speed (ft/min)
S30FT 3000 PSI 2.0L Electronic Powershift or DuraMatch 1 speed 10.7 118
S35FT 3500 PSI 2.0L Electronic Powershift or DuraMatch 1 speed 10.7 118
S40FTS 4000 PSI 2.0L Electronic Powershift or DuraMatch 1 speed 10.7 118
