Features
  • The MSW025-030F has been designed using a separately excited drive motor in conjunction with an advanced transistorized hoist and traction controller to enhance truck performance and reliability.
  • The MSW025-030F bottom mounted tiller handle design optimizes the operating position and reduces steering effort.
  • Outriggers are field adjustable to 37', 42' and 49' ID-45', 50' and 57' OD.
  • Three performance modes, easily changed by the operator through the control handle, allow you to tailor truck performance to the application.
  • The MSW025-030F straddle stacker truck excels in work environments or on a back dock with two or three levels of stacking.

Models
Model Model Designation Load Capacity (lbs.) Battery Maximum Travel Speed (mph) Maximum Lift Speed (ft/min) Lower Lift Speed (ft/min)
MSW025-F Pallet Stackers 2500  24 3.5 30 60
MSW030-F Pallet Stackers 3000  24 3.5 30 60
MSW040-E Pallet Stackers 4000  24 3.6 27.5 52.5
  • Capacity: 2,500 – 3,000 lbs
  • Max Height: 186
  • Max Weight: 4000 lbs
  • Series Title: MSW025F-30F-MSW040E
  • Type: Electric Straddle Stackers
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/pallet-movers/MSW025F-30F-MSW040E

Spec Sheet
MSW040E Spec Sheet
MSW030-40E Brochure
