Features
  • Fingertip control of all truck functions with either hand aids steering and pallet positioning in tight spots.
  • Reduced wiring complexity and fewer service parts contribute to less required maintenance and longer truck life.
  • The Auto Deceleration System extends traction motor brush and brake life by automatically slowing the truck when the accelerator is released, translating to a longer life – and more time spent working.
  • Optional environmental packages including our Cooler/Freezer Package, SubZERO Package ensure that our trucks will stand up to some of the toughest working conditions.

Models
  • Model Load Capacity (lbs) Battery Maximum Travel Speed (mph) Maximum Lift Speed (ft/min) Lower Lift Speed (ft/min) Fork Length
    W60Z 6000 24 3.7 3.7 3 36,42,48
    W65Z 6500 12 3.6 5.7 5.1 36,42,48
    W80Z 8000 24 3.6 3.7 3.2 36,42,48
  • Capacity: 6,000 - 8,000 lbs
  • Max Height: 9.3
  • Max Weight: 8000 lbs
  • Series Title: W60-W80Z
  • Type: Walkie Pallet Trucks
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/pallet-movers/W60-W80Z

Product Brochure
Technical Guide
