Features
  • Optional cold storage cabin provides a more comfortable work environment in -22°F (-30°C) conditions
  • Optional hydraulically operated extendable forks provide up to 30% more storage density
  • 36 month/6,000 hour powertrain limited warranty
  • Choice of 180°/360° steering for seamless direction changes in narrow aisles
  • 12 month/unlimited hours full truck limited warranty
  • Standard Accutouch mini-lever or optional joystick for simplified control
  • Maximum travel speeds of 8.7 mph, mast speeds up to 143 fpm and lifting heights up to 502”
  • Ergonomically designed side seated compartment, full suspension adjustable seat and adjustable steering column
  • Robust mast design provides higher residual capacities and stable load handling, enabling faster put away and retrieval times
  • Lifetime frame warranty
  • Premium touch screen display allows continuous awareness of operational status, by providing PIN access, height preselect, fleet management information, weight indication, lift interrupt override and creep speed selection, when equipped with applicable options
  • Dual CANbus technology identifies operator errors and malfunctions, helping determine problems for a fast fix
  • ‘Get Home’ function can be activated after all functions come to rest, allowing operators to drive the truck to an appropriate place for repair

Models
  • Model Load Capacity (lbs.) Battery Maximum Travel Speed (mph) Maximum Lift Speed (ft/min) Lower Lift Speed (ft/min)
    MR14 3000 48 8.7 143 108.3
    MR16 3500 48 8.7 143 108.3
    MR16N 3500 48 8.7 143 108.3
    MR16HD 3500 48 8.7 143 108.3
    MR20 4500 48 8.7 126 108.3
    MR20HD 4500 48 8.7 133 108.3
    MR25 5500 48 8.7 126 108.3
  • Capacity: 3,000 - 5,500 lbs
  • Max Height: 501
  • Max Weight: 5500 lbs
  • Series Title: MR14-25
  • Type: MR Moving Mast Reach Truck
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/reach-trucks/MR14-25

MR14-25 Spec Sheet
MR14-25 Brochure
