Features
  • Hyster also offers the T7ZAC Heavyweight Handler™ option designed to unload flat-pack and odd-shaped, single-pack items from trailers with greater ease and speed, helping cut unloading times up to 50% and decrease labor up to 40%
  • Environmental packages include cooler / refrigerated, intermittent freezer applications, and spark proof protection. • Four user selectable performance modes and a user friendly multi-function display.
  • A selectable range of extended shift performance modes, on-board diagnostic tool capabilities
  • Customizing the truck to the application, customizing to the skill level of the operator, customizing a password protected performance set-up menu.
  • Hyster® i3 Technology™ integrates commonality among Hyster warehouse products and simplifies the way in which operators and technicians alike handle and service the truck. The Integrated Intelligent Interface ties together functionality, software, diagnostic codes, similar interfaces and is Hyster Tracker compatible. This technology allows operator input to optimize performance to suit operator skill level. It also provides setup and diagnostic menus for service technicians.
  • The state-of-the-art CANbus electrical system reduces wiring and electrical connections, streamlining communications and improving reliability and serviceability.
  • Welded, heavy duty steel constructed frame with steel castings for high stress areas provide superior rigidity and unrivaled durability.

Models
  • Model Model Designation Load Capacity (lbs) Battery Maximum Travel Speed (mph)
    T5ZAC Tow Tractor 10000 24 7.8
    T7ZAC Tow Tractor 15000 24 8.4
    T7ZAC Heavyweight Handlerâ„¢ Tow Tractor 1500 24 8.4(no load); 8.3(with 200 lb. load)
  • Capacity: 10,000 - 15,000 lbs
  • Max Height: 0
  • Max Weight: 15000 lbs
  • Series Title: T5-T7Z
  • Type: Tow Tractors
  • Weight: lbs

Documentation

Download at http://www.riekesequipment.com/new-equipment/forklifts/tow-tractors/T5-T7Z

Brochure / Technical Guide
